PH1100 EU Series (18-25KW)
ModelPH11-18KL3-EU, PH11-20KL3-EU, PH11-25KL3-EU
On/Off Grid Hybrid Solar Inverter — Hybrid Solar Inverter (Three Phase, 380VAC, IP66, Homeload) (18000W / 20000W / 25000W)
At a glance
- Rated Output Power
- 18000W / 20000W / 25000W
- Nominal Battery Voltage
- 48V
Series ranges may cover several models. Confirm your required configuration with our team.
0 / 3 selected in this product family. Your shortlist stays in this tab.
Ask our team for current pricing and availability for this model.
Applications
Residential / Commercial Hybrid Solar
Key features
- Starting-load review: PH11-18KL3-EU, PH11-20KL3-EU and PH11-25KL3-EU list rated output of 18kW, 20kW and 25kW respectively. Request the exact model’s surge rating and duration, and compare the equipment’s starting requirements before selecting it for pumps, motors or compressors.
- Model-specific input limits: PH11-18KL3-EU lists 330A maximum battery charge/discharge current and 36kW maximum DC input power; PH11-20KL3-EU lists 350A and 40kW; PH11-25KL3-EU lists 400A and 50kW. Confirm the supplied model’s battery and PV operating limits before designing the system.
- Programmable 6 Time-of-Use (ToU) segments for peak shaving and electricity bill optimization.
- High parallel scalability up to 16 units in off-grid mode to handle demanding commercial requirements.
- Rugged IP66 rating with large touchscreen display and versatile connectivity (WiFi, Bluetooth, RS485, Ethernet).
